OTAL amphibious Land Rover

History

The OTAL (One Ton Amphibious Land Rover) was built in 1965 as a one-off prototype for evaluation by the Australian Army. It was based on a Land Rover One Ton chassis (chassis number 97/1, registration KYY 501C) with the 2.6-litre six-cylinder petrol engine and four-speed gearbox. Rather than adding a boat hull, the design made the vehicle's own bodywork float: the cab, wings and rear body were built as watertight aluminium compartments, with every spare space stuffed with expanded foam for buoyancy. There was no propeller or water jet — propulsion and steering in the water came from the rotating tyres, which is why the sides carry unusually deep sealed compartments.

The prototype swam at Packington in 1966 and went to Australia for trials, but was never accepted and returned to the UK. In the early 1970s it lived at Eastnor Castle, Land Rover's traditional test estate, and by 1983 it had passed to the British Motor Industry Heritage Trust at Gaydon. The Dunsfold Collection acquired it and carried out a full restoration in 2008; in 2013 the restored OTAL took part in the Land Rover 65th Anniversary event at Packington Park, tested on the same slipway used during its original trials. It remains part of the Dunsfold Collection.

Registry record

Manufacturer

Land Rover (The Rover Company)

Manufactured

1965 prototype

Engine type

2.6 L petrol inline-six

Production run

1 prototype (chassis 97/1)

Current owner

The Dunsfold Collection ↗

Country of origin

United Kingdom

Status

preserved (restored 2008)

Catalogue data

Record kind

Named model

Model line

Series IIA

Wheels

4

Base catalogue fields are exported from the Difflocked game. In-game physics values are arcade tuning, not certified historical measurements, and are deliberately not shown as specifications here.

Sources & citations

Researched sources

• 1965 OTAL One Ton Amphibious Land Rover (one-off prototype for Australian army trials; watertight aluminium compartments and expanded-foam buoyancy; propulsion and steering by the tyres; Eastnor, BMIHT Gaydon, restored by Dunsfold 2008) ↗ — The Dunsfold Collection (accessed 2026-09-10)
• OTAL One Ton Amphibious Land Rover, 1965 — prototype built for the Australian army on a Land Rover One Ton with a six-cylinder engine ↗ — carsthatnevermadeitetc (Tumblr) (accessed 2026-09-10)

Catalogue references

• https://dunsfoldcollection.co.uk/collection/otal/ https://dunsfoldcollection.co.uk/collection/otal/ ↗

Development reference notes

• OTAL amphibious Land Rover · HERITAGE-FLEET-REFERENCES.md

  Boxy sealed hull around a familiar cab; unusually deep side compartments. Reference: https://dunsfoldcollection.co.uk/collection/otal/
